Technical Data;
Working temperature range (°C) : -38 ... +80
Temperature control : PID, cascade
Temperature stability (°C) : ±0.05
Temperature control : PID cascade temperature control
Setting / display resolution : 0.01
Integrated programmer : 1x10 steps
Temperature Display : VFD
Heating capacity (kW) : 2
Cooling capacity (Medium Ethanol) @20 °C : 0.92 kW
Pump capacity flow rate (l/min) : 11-16
Pump capacity flow pressure (bar) : 0.23-0.45
Bath opening / bath depth (W x L / D cm) : 35 x 41 / 27
Filling volume (liters) : 45
Refrigerant stage 1 : R404A
Filling volume refrigerant stage 1 (g) : 350
Global Warming Potential for R404A : 3922
Carbon dioxide equivalent stage 1 (t) : 1.373
External Pt100 sensor connection : integrated
Digital interfaces : RS232
Optional : Profibus
Ambient temperature : 5...40 °C
Dimensions W x L x H (cm) : 46 x 70 x 89
Weight (kg) : 72
Classification according to DIN12876-1 : Classification III (FL)
Cooling of compressor : Air
