Technical Data
Working temperature range (°C): +20 ... +150
Temperature stability (°C): ±0.01
Setting / display resolution: 0.01 °C
Integrated programmer: 1x10 steps
Temperature Display: VFD
Heating capacity (kW): 2
Pump capacity flow rate (l/min): 11-16
Pump capacity flow pressure (bar): 0.23-0.45
Bath opening / bath depth (W x L / D cm): 9 x 9 (2 x) / 27.5
Filling volume (liters): 18
External Pt100 sensor connection: integrated
Digital interfaces: RS232
Optional: Profibus
Ambient temperature: 5...40 °C
Dimensions W x L x H (cm): 36 x 24 x 54
Weight (kg): 17
Classification according to DIN12876-1: Classification III (FL)
Cooling coil: integrated
Bath tank Stainless: steel
Number of viscometers: 2
