Technical Data
Working temperature range (°C): +20 ... +60
Temperature stability (°C): ±0.01
Setting / display resolution: 0.01 °C
Integrated programmer: 1x10 steps
Temperature Display: VFD
Heating capacity (kW): 2
Pump capacity flow rate (l/min): 11-16
Pump capacity flow pressure (bar): 0.23-0.45
Bath opening / bath depth (W x L / D cm): 9 x 9 (3 x) / 37
Filling volume (liters): 31
External Pt100 sensor connection: integrated
Digital interfaces: RS232
Optional: Profibus
Ambient temperature: 5...40 °C
Dimensions W x L x H (cm): 50 x 20 x 56
Weight (kg): 11
Classification according to DIN12876-1: Classification III (FL)
Cooling coil: integrated
Bath tank: Plexiglass
Number of viscometers: 3
