With their high level of flexibility and innovation, Nabertherm offers the optimal solution for customer-specific applications.
The temperature in each of the six heating zones is separately controlled.
Tmax 1300 °C
Heated length: 1300 mm
Charging from the top or through the right side door
Gas damper suspension of the lid
Separate control of heating zones (each 160 mm long)
Temperature gradient of 400 °C over the entire length of the kiln chamber, each zone can individually be controlled
Tmax 1000 °C, 1300 °C, or 1400 °C
Crucible sizes of 0.75 liters, 1.5 liters or 3 liters
Crucible with integrated pouring spout of clay-graphite included with delivery
Additional spout (not for KC 4/14), mounted at the furnace for exact pouring
Compact bench-top design, simple emptying of crucible by tiltiing system with gas damper
Crucible for heating up of melting furnace insulated with a hinged lid, lid opened when pouring
Defined application within the constraints of the operating instructions
Controller R7 (resp. 3508 for KC)
The combination of high performance, low thermal mass and powerful cooling fans provides for cycle times from cold to cold up to 35 minutes with an opening temperature of approx. 300 °C.
Tmax 1300 °C
Floor and lid heating, two-zone control
Dual shell housing made of textured stainless steel sheets with additional fan cooling for low surface temperature
Integrated cooling fans, programmable to speed up charge cooling including housing cooling
Programmable lid opening of approximately 60 mm for faster cooling without activating the fan
Thermocouple type S for top and bottom zone
Castors for easy furnace moving
Defined application within the constraints of the operating instructions
Controller P570 (50 programs with each 40 segments)
