High-Temperature Furnaces up to 1800 °C

Tmax 1600 °C or 1700 °C
Robust refractory brick insulation and special backing insulation
Furnace floor made of lightweight refractory bricks accommodates high charge weights

Tmax 1650 °C
High-quality heating elements made of molybdenum disilicide offer very good protection against chemical interaction between charge and heating elements
Excellent temperature uniformity thanks to three (LHT 02/17 LB Speed) or four-sided (LHT 01/17 LB Speed) heating of the furnace chamber
Furnace chamber with a volume of 1 or 2 liters, table with large floor space
Precise, motorized toothed belt drive of the table with button operation
Exhaust air vent in the roof
Type S thermocouple
Controller P580 (50 programs with each 40 segments)

Tmax 1600 °C, 1750 °C, or 1800 °C
Recommended working temperature 1750 °C (for models HT ../18)
Dual shell housing with fan cooling for low shell temperatures
Heating from both sides via molybdenum disilicide heating elements
High-quality fiber insulation backed by special insulation
Side insulation constructed with tongue and groove blocks provides for low heat loss to the outside
Long-life roof insulation with special suspension
Chain-guided parallel swivel door for defined opening and closing of the door
Two-door design (front/back) for high-temperature furnaces > HT 276/..

Tmax 1600 °C, 1750 °C, or 1800 °C
Recommended working temperature 1750 °C
High-quality molybdenum disilicide heating elements
Dual shell housing made of textured stainless steel sheets with additional fan cooling for low surface temperature
Adjustable air inlet opening, exhaust air opening in the roof
Type B thermocouple
Controller P470 (50 programs with each 40 segments)

Tmax 1600 °C or 1750 °C
High-quality molybdenum disilicide heating elements
Dual shell housing made of textured stainless steel sheets with additional fan cooling for low surface temperature
Adjustable air inlet
Exhaust air opening in the roof
Type B thermocouple
4 scales available for different maximum weights and scaling ranges
Process control and documentation for temperature and combustion loss via VCD software package for monitoring, documentation and control

Tmax 1550 °C
Dual shell housing with fan cooling for low shell temperatures
Heating from both sides via vertically mounted SiC rods
High-quality fiber insulation backed by special insulation
Two-door design (front/back) for high-temperature furnaces > HTC 276/..

Tmax 1550 °C or 1600 °C
Working temperature 1500 °C, increased wear and tear must be expected in case of working at higher temperatures
Dual shell housing made of textured stainless steel sheets with additional fan cooling for low surface temperature
Adjustable air inlet opening, exhaust air opening in the roof
Controller C550 (10 programs with each 20 segments)
